High-Performance Euro Cap Assembly Machine for Fast and Accurate Assembly with 99% Satisfactory Rate and 4500-12000 per/hour Capacity

Nama merek:	SENCAN
Nomor Model:	SC-TP-814
MOQ:	1 Set
harga:	Negotiate price according to actual situation
Ketentuan Pembayaran:	T/T,L/C
Kemampuan Pasokan:	2-20 Set

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

CINA

Sertifikasi:

CE, ISO9001

Pengukur tekanan udara:

Smc

Kecepatan operasi:

Dapat disesuaikan

Metode operasi:

Turntable/Mechanical

Rasio efisiensi:

di atas 95%

Orang Operasi:

1 orang

Bahan:

Baja Tahan Karat

Daya produk:

220v

Frekuensi:

50/60Hz

Kapasitas perakitan:

4500-12000 per jam

Operator:

Lajang

Tingkat yang memuaskan:

Sekitar 99%

Tutup yang berlaku:

Euro Caps

Modus Operasi:

Setengah otomatis

Mekanisme:

Servo

Kemasan rincian:

Kasus kayu

Menyoroti:

Fast and Accurate Euro Cap Assembly Machine

99% Satisfactory Rate Infusion Cap Assembly Machine

4500-12000 per/hour Automatic Cap Assembly Machine

Deskripsi Produk

High-Performance Euro Cap Assembly Machine for Fast and Accurate Assembly

Product Features

Designed for automatic assembly of easy peel foil caps for IV infusion soft bags and bottles
Constructed with stainless steel and aluminum alloy materials, compliant with GMP standards
Independent driving source for each workstation, facilitating easy maintenance
Product-contact surfaces polished for optimal product protection
Automated foil cutting and welding process
Integrated check function after each assembly step to ensure product quality
PLC control system with user-friendly interface, requiring minimal operator training
Servo motor + indexing drive power system for high precision assembly and qualification rates
Pneumatic power system reduces maintenance time and technical requirements
Fully customizable to meet specific product specifications, capacity, and production demands

Technical Specifications

Applicable Products	Peel seal foil caps, foil seal closures and lids
Production Speed	1500-8500pcs/hr (customizable to customer requirements)
Qualified Product Rate	Above 99%
Operation Rate	Above 95%
Power Source	AC380V, 50Hz, 4kw/hr
Dimensions	Varies according to production speed requirements
Weight	Approximately 2000kg
Operator Requirements	3 sets/2 persons, recommended 1 set/person
